Shotgun Shell Limiters (Plugs)







Benelli Shell Limiters



Part B2400-1
Benelli SBE / SBE II Shell Limiter
limits Mag to 2 shells [2-3/4;3;3-1/2]

Polished Aluminum Finish

Price : $15.00

Part B2400-4
Benelli Nova Shell Limiter
limits Mag to 2 shells [2-3/4;3;3-1/2]

Polished Aluminum Finish

Price : $16.00



Part B2400-3G
Benelli SBE / SBE II Shell Limiter with
4 shot Extension Attached
Limits Mag to 2 shells [2-3/4;3;3-1/2]

Green Olive Anodizing

SOLD OUT
Price : $25.00

Part B2400-3B
Benelli SBE / SBE II Shell Limiter with
4 shot Extension Attached.
Limits Mag to 2 shells [2-3/4;3;3-1/2]

BLACK Anodizing

SOLD OUT
Price : $25.00






Installation Guide:

Remove Old Limiter below the Spring Retainer.

Snap ring plyers can be useful

WATCH OUT, the coiled spring is in compressed and it can wack you, be careful.

Install spring and retainer, retainer should be recessed in tube around 1/4"

Slide in new limiter and add Magazine Cover.



Limiter installed in Nova





Plastic Limiter in Nova needs to be removed, Watch out for Spring





Nova ready for new limiter now





Slide that Limiter in.





4 shot Extension Tube.

Measurement Guide: (how to measure limiter sizes)

PHOTO of shells and description below

3- 1/2" shells on Bottom, 3 " in middle & 2- 3/4"shells on top row.

The last shell on the right is a a 2 - 3/4" shell. [ BOTTOM ROW ]

With the limiter installed you should have ~ 6 1/2" of length available in the magazine tube for shells.



Getting a length number can be done in many ways.

You can use pencils and shells among other devices.

Fill the magazine with shells until it is full. the last shell should be sticking out and you can mark it with a sharpie. Unload the shotgun and then line up the shells next to a ruler. Use picture above to get the 6-1/2" max length.

e.g. Your shells line up to 10-1/2" , so you need a 4 inch limiter length
